ASUS TUF Gaming B850-PLUS WiFi AMD AM5 B850 ATX Motherboard, 14+2+1 80A Stages, AI Ready, DDR5, PCIe 5.0, 3X M.2, Wi-Fi 7, 2.5Gb LAN, DisplayPort, HDMI™, USB 10Gbps & 20Gbps Type-C®, BIOS Flashback™

TUF GAMING B850-PLUS WIFI
CPU & Chipset

• Socket: AMD AM5

• Supported CPUs: AMD Ryzen™ 9000, 8000 & 7000 Series

• Chipset: AMD B850

Memory

• DIMM Slots: 4 (Max 256GB DDR5)

• Speed: Up to 8000+MT/s (OC)

• Features: Dual Channel, ECC & Non-ECC Unbuffered DIMM, AMD EXPO™, ASUS AEMP

Graphics

• Display Outputs: 1 × DisplayPort (8K@30Hz), 1 × HDMI (4K@60Hz)

• Depends on CPU Graphics Capabilities

Expansion Slots

• Ryzen™ 9000 & 7000 Series:

• 1 × PCIe 5.0 x16 (x16 mode)

• Ryzen™ 8000 Series:

• 1 × PCIe 4.0 x16 (x8/x4 mode)

• AMD B850 Chipset:

• 1 × PCIe 4.0 x16 (x4 mode, shares bandwidth with M.2_3)

• 2 × PCIe 4.0 x1

Storage

• M.2 Slots: 3 × M.2 (PCIe 5.0/4.0)

• SATA Ports: 4 × SATA 6Gb/s

• RAID Support: RAID 0/1/5/10 (varies by CPU)

Networking

• Ethernet: Realtek 2.5Gb

• Wi-Fi: Wi-Fi 7 (2x2)

• Bluetooth: v5.4

USB Ports

• Rear I/O (10 Total):

• 1 × USB 20Gbps (Type-C)

• 3 × USB 10Gbps (Type-A)

• 4 × USB 5Gbps (Type-A)

• 2 × USB 2.0 (Type-A)

• Front Panel (7 Total):

• 1 × USB 10Gbps (Type-C)

• 1 × USB 5Gbps (2 ports via header)

• 2 × USB 2.0 headers (4 ports)

Audio

• Codec: Realtek ALC1220P (7.1 Surround Sound)

• Features:

• High SNR, Internal Amp, Jack Detection, Premium Capacitors, Shielding

• Supports 32-bit/192 kHz Playback (Stereo Only)

Back Panel I/O

• USB: 10 ports (as listed above)

• Video: 1 × HDMI, 1 × DisplayPort

• Network: 1 × 2.5Gb Ethernet, 1 × Wi-Fi 7 Module

• Audio: 5 × Audio Jacks

• Other: 1 × BIOS FlashBack™ Button

Internal Connectors

• Cooling:

• 1 × CPU Fan

• 1 × CPU OPT Fan

• 1 × AIO Pump

• 4 × Chassis Fans

• Power:

• 1 × 24-pin ATX

• 2 × 8-pin CPU

• USB Headers:

• 1 × USB 10Gbps (Type-C)

• 1 × USB 5Gbps (2 ports)

• 2 × USB 2.0 headers (4 ports)

• Miscellaneous:

• 3 × Addressable Gen 2 RGB Headers

• 1 × Thunderbolt™ (USB4) Header

• Clear CMOS, Chassis Intrusion, COM Port, Front Audio

Special Features

• TUF Protection: ESD Guards, Overvoltage Protection, SafeSlot, Stainless I/O

• Q-Design: Q-Release, Q-DIMM, Q-LED Diagnostics

• Cooling: M.2 & VRM Heatsinks

• EZ DIY: BIOS FlashBack™, Pre-mounted I/O

Software & BIOS

• ASUS Exclusive Software: Armoury Crate, Fan Xpert 4, TurboV Core, CPU-Z

• BIOS: 256Mb UEFI AMI BIOS with EZ Mode & CrashFree

Accessories

• 2 × SATA 6Gb/s Cables

• 1 × ASUS Wi-Fi Q-Antenna

• 2 × M.2 Rubber Packages

• 1 × TUF GAMING Sticker

• 1 × Quick Start Guide

Form Factor

• Size: ATX (30.5 cm × 24.4 cm)

• OS Support: Windows 11
