MSI MEG Z890 GODLIKE Intel LGA 1851 E-ATX Motherboard
from
56,999 L.E
- Stock: In Stock
- Brand: MSI
- Model: 911-7E21-002
Tags:
MSI
, MEG
, GODLIKE
, Z890
, Intel LGA 1851
, E-ATX
, Gaming Motherboard
, DDR5
, PCIe 5.0
, Wi-Fi 7
, 10GbE LAN
, 5GbE LAN
, Thunderbolt 4
, 8x M.2
, ESS DAC
, Dynamic Dashboard
, Intel Core Ultra Ready
, PC Components Egypt
ULTIMATE FLAGSHIP E-ATX GAMING & OVERCLOCKING MOTHERBOARD
MSI MEG Z890 GODLIKE Intel LGA 1851 E-ATX Motherboard
Full Product Specifications
| CPU & Chipset | |
|---|---|
| Brand & Series | MSI MEG (GODLIKE Series) |
| CPU Socket | Intel® Socket LGA 1851 |
| Supported Processors | Intel® Core™ Ultra Processors (Series 2) |
| Chipset | Intel® Z890 |
| Form Factor | E-ATX Form Factor |
| Memory Support | |
| Memory Type | DDR5 (4 × UDIMM Slots, Dual-Controller Dual-Channel) |
| Max Capacity | Up to 256 GB (64 GB per slot) |
| Supported Speeds | JEDEC: 4800 – 6400 MT/s | Overclocked: Up to 9200+ MT/s (1DPC 1R) / 7200+ MT/s (1DPC 2R) |
| Features & Profiles | Intel® XMP 3.0, CUDIMM Support, Non-ECC Un-buffered Memory |
| Expansion & Storage Interfaces | |
| PCIe Expansion Slots | 2 × PCIe 5.0 x16 (PCI_E1/E2 from CPU, supports x16/x0 or x8/x8) + 1 × PCIe 4.0 x4 (PCI_E3 from Chipset) |
| Total M.2 Slots | 8 × M.2 Slots (6 Onboard [2x Gen5 + 4x Gen4] + 2x Gen5 via M.2 XPANDER-Z SLIDER GEN5 Card) |
| SATA Ports | 4 × SATA 6Gb/s Connectors |
| RAID Support | RAID 0/1/5/10 for M.2 NVMe SSDs | RAID 0/1/5/10 for SATA Drives |
| Connectivity & Audio | |
| Thunderbolt™ 4 / USB4 | 2 × Thunderbolt™ 4 Type-C® (40Gbps, DisplayPort 2.1 UHBR20 8K/4K@120Hz, 15W Charging) |
| Networking & Wireless | Dual Wired LAN (Marvell® 10GbE + Intel® Killer™ 5GbE) + Intel® Killer™ Wi-Fi 7 (320MHz, 5.8Gbps) + Bluetooth 5.4 |
| Front Panel Fast Charge | 1 × USB 20Gbps Type-C® Header (Supports USB PD 60W Fast Charging with PD_PWR1) |
| Audio CODEC | Realtek® ALC4082 + ESS9219Q Combo DAC/HPA (7.1-Ch, Up to 32-bit/384kHz, Optical S/PDIF Out) |
| Exclusive Onboard Tech | Dynamic Dashboard III, EZ Digi-Debug LED, Smart Button, Thunderbolt 5 Card Connector (JTBT5) |
